Application and Features of Gravimetric Blender

Aug. 24, 2020

     Aumax GB series of Gravimetric Blender (Mixer) adopts German Siemens PLC control system, adopts advanced batching algorithm, can be automatically calibrated according to the actual feeding volume to ensure accuracy, and the operation screen is simple, easy to learn and operate. GB series of Gravimetric Mixer uses high-precision weight sensors to control the batch mixing ratio difference within ±0.1% to ±0.3%. Customers choose the appropriate model according to the hourly usage and the number of types to be processed.



Features

1. Modular and detachable structure design, easy to maintain and clean;

2. Using the latest vertical metering valve, the blanking is smooth, not easy to jam, and has a long life;

3. Equipped with buzzer and warning light alarm, equipment operators can quickly and accurately reach the faulty machine site;

4. Adopt brand PLC controller to ensure reliable performance and easy maintenance;

5. Adopt brand man-machine interface, graphical screen, intuitive and easy to understand operation, and there are multiple languages for you to choose;

6. The use of advanced control algorithms, independent optimization, and automatic adjustment of compensation and vibration prevention functions to ensure the accuracy of ingredients;

7. With formula storage function, it can store more than 100 groups of formulas at most;

8. With hierarchical security password control and alarm history record function;

9. It has weighing, volume and mixed measurement modes for users to choose, which can deal with different production situations;

10. All parts in contact with raw materials are made of stainless steel to prevent raw materials from being contaminated;

11. Up to eight kinds of raw materials can be processed simultaneously;

12. It can be directly installed on the machine or can be installed next to the machine with optional tripod;

13. The low level switch of the batching hopper can be selected, and the material in the hopper can be alarmed in advance when the material level is low;

14. Optional analog signal output function of processing capacity per hour;

15. Optional data storage card can save and record the mixing ratio data to facilitate production quality control.

16. Integrated conveying control function (optional)
