Powerful Plastic Granulator
AMG-300 AMG-400 AMG-500 AMG-600 AMG-700 AMG-800 AMG-800+ AMG-1000
Product details
Introduction
AMG Series Powerful Plastic Granulators and Plastic Crushers are used to granulate various kinds of plastic wastes, products and injection mold sprues. The machine crush different hard and soft plastic wastes in different shapes like PET Bottles, PP/PE films, plastic blocks, plastic thermoforming sheets, plastic balls, plastic twigs, etc. AMG plastic granulators play an important role in plastic recycling industry.
Advantages
-AMG Series powerful granulators are equipped with high quality tool steel blades and high efficiency energy-saving motor. We have 3 different types of blades structure (V-shape type, Claw type and Flat type) for all kinds of plastic materials with different shapes and thickness.
-With special design on machine structure, AMG Series plastic crushers have bigger cutting room with higher crushing capacity than similar models from other manufacturers.
-AMG Series plastic crushers (grinders) adopt global top brand electrical parts to insure safety of peoples and machine, as well as reduce the problem of machines.
Features:
-Special designed blades structure, easy to install and maintenance.
-Special designed bearings block keep dust away, long life using.
-6CrW2Si standard blades material, SKD11 blades material is optional.
-Safety switches to protect people overload device to protect motor.
-Fixed with shockproof pad to reduce vibration and noise.
Main functions
AMG Series plastic granulators are used to crush plastic wastes, defective plastic products, injection mold sprues, blowing mold sprues, PET bottles, thermoforming sheets, etc. to be small pellets, granules and scraps material. In that case, the wasted plastics can be easily melted and reused again.
AMG Series strong plastic crushers are popular and used in plastic injection molding factories, plastic recycling plants, plastic blowing molding factories, plastic pelletizing factories and so on.
Plastic materials before crushing and after crushing:
Specification:
Name | Powerful Plastic Granulator / Strong Plastic Crusher | |||||||||
Model | AMG-300 | AMG-400 | AMG-500 | AMG-600 | AMG-700 | AMG- 800 | AMG- 800+ | AMG- 1000 | ||
Power | kw | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | |
Rotor Diameter | mm | 260 | 360 | 460 | ||||||
Rotor Speed | rpm | 560 | 560 | 560 | ||||||
Rotating Blades | V type | pcs | 3 | 6 | 6 | 6 | 6 | 6 | 6 | 6 |
F type | 9 | 12 | 15 | 18 | 21 | 24 | 24 | |||
C type | 18 | 24 | 30 | 30 | 36 | 42 | 42 | |||
Fixed Blades | pcs | 2 | 2 | 2 | 4 | 4 | 4 | 4 | 4 | |
Screen Diameter | Ø10 | Ø12 | Ø12 | |||||||
Chamber Size | mm | 370x300 | 370x400 | 370x500 | 480x600 | 480x700 | 480x800 | 560x 800 | 560x 1000 | |
Output | kg/h | 270~ 350 | 300~ 500 | 400~ 600 | 500~ 700 | 600~ 800 | 700 ~900 | 800~ 1200 | 1000~1500 | |
Noise | dB(A) | 80~95 | 80~95 | 80~95 | ||||||
Magnet at Feeding Mouth | O | O | O | |||||||
Blower Conveying & Cyclone System | O | O | O | |||||||
Manual Box | √ | √ | √ | |||||||
Weight | kg | 490 | 530 | 600 | 1050 | 1150 | 1250 | 1550 | 1750 | |
Dimensions: | ||||||||||
L | mm | 1420 | 1760 | |||||||
W | mm | 830 | 930 | 1030 | 1170 | 1270 | 1370 | |||
H | mm | 1410 | 1835 |
Please excuse for not note if some specifications of products are
changed.
Note:
1)"√"is standard configuration," O " is optional to purchase.
2) “V” Type rotating blades is standard type; F Type flat rotating blades and C type claw rotating blades is optional to purchase.
3)The maximum crushing output depends on the screen diameter, material quality and feeding frequency.
4) The screen mesh diameter can be made according to customers’ request.
5)The running noise depends on varied shredding material.
6)The standard power supply is 3Ø 380V 50Hz. Other power supply is available.
Certifications:
We have CE Certification for all of our AMG Series plastic granulator machine.
Our service:
-We supply one year warranty for machines we supplied.
-We provide 24 hours online support for installation, using, repairing and maintenance.
-If necessary, we can supply to-door service for installation and repairing of machine in customer’s factory.
