Product Name:

Heavy-duty Centralized Granulator

Model No.:

AMG-1000SH AMG-1200SH AMG-1400SH


Product details

Specification:

NameHeavy Duty Centralized Granulator / Crusher/ Grinder
ModelAMG-1000SHAMG-1200SHAMG-1400SH
Powerkw75110132
Rotor Speedrpm450450450
Rotating Bladespcs666
Fixed Bladespcs444
Screen Diameter
Ø12Ø12Ø12
Chamber Sizemm870x1000870x1200870x1400
Outputkg/h1500~25001800~28002000~3000
NoisedB(A)100~120100~120100~120
Blower Conveying & Cyclone System4KW x 2pcs4KW x 2pcs4KW x 2pcs
Hydraulic System for lifting of Hopper and Screen
Weightkg496062007800
Dimensions:
Lmm229022902290
Wmm198021402340
Hmm324032403240

Please excuse for not note if some specifications of products are changed.


Note:

1)"√"is standard configuration," O " is optional to purchase.

2)The output capacity depends on the screen diameter, material quality and feeding frequency.

3) The screen mesh diameter can be made according to customers’ request.

4)The running noise depends on varied shredding material.

5)The standard power supply is 3Ø 380V 50Hz. Other power supply is available.

Heavy-duty Centralized Granulator


Application:

AMG-SH Series granulators are specially designed for crushing and recycling of all kinds of plastic wastes, rubber fabric, leather, cardboards, wooden sheets, timber aluminum foil in shape of sheets, films, sprues wires,, tubular construction or hollow containers. This series plastic crushers also can crush different hard and soft plastic wastes like PET Bottles, PP/PE films, PVC pipes and fittings, plastic blocks, thermoplastic sheets, electric wires, etc. Large rotor shaft diameter, cutting chamber size and motor power insures machine can crush large material with big output capacity.


Features:

High-intensity rotor shaft, blades and screws insures a heavy-duty performance.

External bearings block fixed outside machine body, keep dust away and low temperature.

V-shaped designed blades structure and SKD11 material blades insures a high cutting efficiency.

Hydraulic system for opening and closing cutting chamber and screen room to save manpower.

Separate structure design for cutting chamber and screen room, easy to clean and maintenance.

Safety switch and overload device to protect safety of people and motor.

Equipped with anti-vibration pad to reduce vibration and noise.
